AM50L●AM75L●AM100L●AM125L●AM150L●Universal Pump●에어 바큠 펌프●에어 진공 펌프●에어 버큠 펌프●에어 진공 이젝터●에어 진공 발생기●에어 유니버셜 진공펌프●(-92kPa)●(1500L/min)●(Air Best)●(AIRBEST)

 AM 카탈로그    Airbest Catalog-A B part Airbest Catalog-C part Airbest Catalog- D part Airbest Catalog-E F G part

●(at 6bar) Vacuum Pump

(material=AL) (sealing=NBR) (vacuum=-89kPa)

●AM25L-AD-N (vacuum flow=420NL/min) (csq1769)

(air=G1/4 F) (vacuum=G3/4 F) (EX=G3/4 F)

●AM50L-AD-N (vacuum flow=700NL/min) (csq1770)

(air=G1/4 F) (vacuum=G3/4 F) (EX=G3/4 F)

●AM75L-AD-N (vacuum flow=950NL/min) (csq1771)

(ais=G1/4 F) (vacuum=G3/4 F)( EX=G3/4 F)

●AM100L-AD-N (vacuum flow=1010NL/min) (csq1772)

(air=G1/4 F) (vacuum=G3/4 F) (EX=G3/4 F)

●AM125L-AD-N (vacuum flow=1400NL/min) (csq1773)

(air=G1/4 F) (vacuum=G1 F) (EX=G3/4 F)

●AM150L-AD-N (vacuum flow=1500NL/min) (csq1774)

(air=G1/4 F) (vacuum=G1 F) (EX=G3/4 F)

●(at 3bar) Vacuum Pump

(material=AL) (sealing=NBR) (vacuum=-92kPa)

●AM25L-AD-N (vacuum flow=360NL/min) (csq1769)

(air=G1/4 F) (vacuum=G3/4 F) (EX=G3/4 F)

●AM50L-AD-N (vacuum flow=600NL/min) (csq1770)

(air=G1/4 F) (vacuum=G3/4 F) (EX=G3/4 F)

●AM75L-AD-N (vacuum flow=760NL/min) (csq1771)

(ais=G1/4 F) (vacuum=G3/4 F)( EX=G3/4 F)

●AM100L-AD-N (vacuum flow=850NL/min) (csq1772)

(air=G1/4 F) (vacuum=G3/4 F) (EX=G3/4 F)

●AM125L-AD-N (vacuum flow=1150NL/min) (csq1773)

(air=G1/4 F) (vacuum=G1 F) (EX=G3/4 F)

●AM150L-AD-N (vacuum flow=1200NL/min) (csq1774)

(air=G1/4 F) (vacuum=G1 F) (EX=G3/4 F)

●(at 6bar) Vacuum Pump

(material=AL) (sealing=EPDM) (vacuum=-92kPa)

●AM25L-AD-E (vacuum flow=420NL/min)

(air=G1/4 F) (vacuum=G3/4 F) (EX=G3/4 F)

●AM50L-AD-E (vacuum flow=700NL/min)

(air=G1/4 F) (vacuum=G3/4 F) (EX=G3/4 F)

●AM75L-AD-E (vacuum flow=950NL/min)

(air=G1/4 F) (vacuum=G3/4 F) (EX=G3/4 F)

●AM100L-AD-E (vacuum flow=1010NL/min)

(air=G1/4 F) (vacuum=G3/4 F) (EX=G3/4 F)

●AM125L-AD-E (vacuum flow=1400NL/min)

(air=G1/4 F) (vacuum=G1 F) (EX=G3/4 F)

●AM150L-AD-E (vacuum flow=1500NL/min)

(air=G1/4 F) (vacuum=G1 F) (EX=G3/4 F)
