AL25●AL50●AL75●AL100●AL125●AL150●Universal Pump●에어 바큠 펌프●에어 진공 펌프●에어 버큠 펌프●에어 진공 이젝터●에어 진공 발생기●에어 유니버셜 진공펌프●(-81kPa)●(1500L/min)●(Air Best)●(AIRBEST)

AL Series 카탈로그   Airbest Catalog-A B part

 Airbest Catalog-C part Airbest Catalog- D part

Airbest Catalog-E F G part

●(at 6bar) Vacuum Pump

 (material=AL) (sealing=NBR) (vacuum=-81kPa)

●AM25L-AD-N (vacuum flow=360NL/min)

(air=G1/4 F) (vacuum=G3/4 F) (EX=G3/4 F)

●AM50L-AD-N (vacuum flow=640NL/min)

(air=G1/4 F) (vacuum=G3/4 F) (EX=G3/4 F)

●AM75L-AD-N (vacuum flow=850NL/min)

(air=G1/4 F) (vacuum=G3/4 F) (EX=G3/4 F)

●AM100L-AD-N (vacuum flow=990NL/min)

(air=G1/4 F) (vacuum=G3/4 F) (EX=G3/4 F)

●AM125L-AD-N (vacuum flow=1170NL/min)

(air=G1/4 F) (vacuum=G1 F) (EX=G1 F)

●AM150L-AD-N (vacuum flow=1500NL/min)

(air=G1/4 F) (vacuum=G1 F) (EX=G1 F)

●(at 6bar) Vacuum Pump

(material=AL) (sealing=EPDM) (vacuum=-81kPa)

●AM25L-AD-E (vacuum flow=360NL/min)

(air=G1/4 F) (vacuum=G3/4 F) (EX=G3/4 F)

● AM50L-AD-E (vacuum flow=640NL/min)

(air=G1/4 F) (vacuum=G3/4 F) (EX=G3/4 F)

●AM75L-AD-E (vacuum flow=850NL/min)

(air=G1/4 F) (vacuum=G3/4 F) (EX=G3/4 F)

●AM100L-AD-E (vacuum flow=990NL/min)

(air=G1/4 F) (vacuum=G3/4 F) (EX=G3/4 F)

●AM125L-AD-E (vacuum flow=1170NL/min)

(air=G1/4 F) (vacuum=G1 F) (EX=G1 F)

●AM150L-AD-E (vacuum flow=1500NL/min)

(air=G1/4 F) (vacuum=G1 F) (EX=G1 F)

●(at 6bar) Vacuum Pump

(material=AL) (sealing=Fluoring nubber) (vacuum=-81kPa)

●AM25L-AD-F (vacuum flow=360NL/min)

(air=G1/4 F) (vacuum=G3/4 F) (EX=G3/4 F)

●AM50L-AD-F (vacuum flow=640NL/min)

(air=G1/4 F) (vacuum=G3/4 F) (EX=G3/4 F)

●AM75L-AD-F (vacuum flow=850NL/min)

(air=G1/4 F) (vacuum=G3/4 F) (EX=G3/4 F)

●AM100L-AD-=F (vacuum flow=990NL/min)

(air=G1/4 F) (vacuum=G3/4 F) (EX=G3/4 F)

●AM125L-AD-F (vacuum flow=1170NL/min)

(air=G1/4 F) (vacuum=G1 F) (EX=G1 F)

●AM150L-AD-F (vacuum flow=1500NL/min)

(air=G1/4 F) (vacuum=G1 F) (EX=G1 F)
