ZB05(D)●ZB07(D)●ZB10●4ZB06●4ZB10●Single acting air drive gas Booster●air drive Gas Booster●싱글타입 에어구동 냉매부스터●에어구동 냉매 펌프●에어 구동 냉매 증압기●에어 드라이브 냉매 부스터●씨택 가스부스터●(max ratio=10:1)●(SITEKE,SITEC)

SITEKE 전체 카탈로그1(중문)

SITEKE 전체카탈로그2(중문)

ZB 카탈로그(영문) ZB 카탈로그(중문)

ZB07D 카탈로그 ZB07 카탈로그 ZB05D 카탈로그

  ZB05 카탈로그 4ZB06 카탈로그 4ZB10 카탈로그

●Single acting air drive Air Booster (air drive Gas Booster)

●Single acting Air Drive Gas Booster (media=air, gas)

●ZB05(D) (ratio=4:1) (foot type) (flow=400g/s)

(Pa=air drive  input pressure=~8.3bar)

(Pi=air & gas in put pressure=0.1bar)

(Po=air & gas max output pressure=33.2bar)

●(Single acting) air drive Air Booster & air drive Gas Booster

●(Single acting) Air Drive Gas Booster (Single stage) (media=air, gas)

●ZB07(D) (ratio=7:1) (foot type) (flow=280g/s)

(Pa=air drive  input pressure=~8.3bar)

(Pi=air & gas in put pressure=3.4bar)

(Po=air & gas max output pressure=56bar)

●(Single acting) air drive Air Booster & air drive Gas Booster

●(Single acting) Air Drive Gas Booster (Single stage) (media=air, gas)

●ZB10 (ratio=10:1) (foot type) (flow=160g/s)

(Pa=air drive  input pressure=~8.3bar)

(Pi=air & gas in put pressure=3.4bar)

(Po=air & gas max output pressure=83bar)

●(Single acting) air drive Air Booster & air drive Gas Booster

●(Single acting) Air Drive Gas Booster (Single stage) (media=air, gas)

●4ZB06 (ratio=6:1) (foot type) (flow=1600g/s)

(Pa=air drive  input pressure=~8.3bar)

(Pi=air & gas in put pressure=3.4bar)

(Po=air & gas max output pressure=48bar)

●(Single acting) air drive Air Booster & air drive Gas Booster

●(Single acting) Air Drive Gas Booster (Single stage) (media=air, gas)

●4ZB10 (ratio=10:1) (foot type) (flow=900g/s)

(Pa=air drive  input pressure=~8.3bar)

(Pi=air & gas in put pressure=3.4bar)

(Po=air & gas max output pressure=83bar)

●(Pa/PD=air driving pressure) (air drive air input pressure=~8.3bar)

●(Pi/PS= air & gas input pressure) (media＝air, He, CO2, H2, Ar, N2)

●(Po/PH=air & gas  output pressure)

●CO2 Pump, CO2 펌프 ● He Pump, 헬륨펌프, helium Pump ●냉매펌프

●H2 Pump,수소펌프 ●N2 Pump, 질소펌프 ●Ar Pump, Ar펌프, 아르곤펌프
