A20-T-(Nikel plated)●(A20T)●2/2way nikel plated Electric Ball Valve●RFS 전기 볼 밸브●RFS 전동 볼밸브●RFS Electric Ball Valve●브라쉬 전동볼밸브●브라쉬 전기 볼밸브●(NPT1/2 F~NPT11/4 F)●(0~15bar)●(RFS)

A20-T Series(BODY-Nickel) 카탈로그

A20-T Series(BODY-Nickel) 코드번호

A20-T Series(BODY-Brass) 카탈로그

Electric Ball Valve 전체 카탈로그

 Electric Ball Valve 전체 코드번호

●(2/2way, nikel plated) Electric ball valve (power reset, 2wire)

(on/off time=5S)

(NO manual) (with open/close Indicator)

(body=nikel plated) (seat=PFTE) (torque=2 Nm)

●A20-T15-N2-C-CR202-(2wires)-(voltage=AC110V~230V)

(NPT 1/2 Female ) (DME7074)

●A20-T15-N2-C-CR202-(2wires)-(voltage=AC/DC9-24V)

(NPT 1/2 Female) (DME7070)

●(2/2way, nikel plated) Electric ball valve (power reset, 2wire)

(on/off time=5S)

(NO manual) (with open/close Indicator)

(body=nikel plated) (seat=PFTE) (torque=2 Nm)

●A20-T20-N2-C-CR202-(2wires)-(voltage=AC110V~230V)

(NPT 3/4 Female) (DME7075)

●A20-T20-N2-C-CR202-(2wires)-(voltage=DC24V)

(NPT 3/4 Female) (DME7071)

●(2/2way, nikel plated) Electric ball valve (power reset, 2wire)

(on/off time=5S)

(NO manual) (with open/close Indicator)

(body=nikel plated) (seat=PFTE) (torque=2 Nm)

●A20-T25-N2-C-CR202=(2wires)-(voltage=AC/DC9-24V)

(NPT 1 Female) (DME7072)

●A20-T25-N2-C-CR202-(2wires)-(voltage=AC110V~230V)

(NPT 1 Female) (DME7081)

●(2/2way,nikel plated) Electric ball valve (power reset, 2wire)

(on/off time=5S)

(NO manual) (with open/close Indicator)

(body=nikel plated) (seat=PFTE) (torque=2 Nm)

●A20-T32-N2-C-CR202-(2wires)-(voltage=AC110V~230V)

(NPT 11/4 Female) (DME7076)

●(2/2way, nikel plated) Electric ball valve (no power reset, 2wires)

(on/off time=5S)

(with manual) (with open/close Indicator)

(body=nikel plated) (seat=PFTE) (torque=2 Nm)

●A20-T15-N2-B-CR201-(2wires)-(voltage=DC24V)

(NPT 1/2 Female) (DME7066)

●A20-T20-N2-B-CR201-(2wires)-(voltage=DC24V)

(NP T3/4 Female) (DME7067)

●A20-T25-N2-B-CR201-(2wires)-(voltage=DC24V)

(NPT 1 Female) (DME7068)

●(2/2way, nikel plated) Electric ball valve

(power reset) (5wires, feedback)

(on/off time=5S)

(with manual) (with open/close Indicator)

(body=nikel plated) (seat=PFTE) (torque=2 Nm)

●A20-T15-N2-C-CR502-(5wires)-(voltage=DC24V)

(NPT 1/2 Female) (csq4677)
